C-Lite Linear LED High Bay Light | C-PHB-C-L2F Series | CCT & Wattage Selectable | Up to 26,100 Lumens | 277-480V | White
Ships in: 10-12 Days
$204.99
SKU: C-PHB-C-L2F-S24L-SCCT-UH-WH
Replaces 6-Lamp - T5HO 54W
Up to 26,100 Lumens
Up to 26,100 Lumens
Product Overview
Replaces 6 x F54T5HO. C-Lite LED Linear High Bay with up to 26,100 delivered lumens. CCT Selectable: 4000K, 4500K and 5000K. Dual-wattage selectable: 125W and 175W, 277-480V, cULus Listed, 5-year limited warranty.
WARNING: Cancer and Reproductive Harm - www.p65warnings.ca.gov
Guides & Info
- Instruction Manual: C-PHB-C-L2F-SCCT Series without EB Download File
- IES Files: C-PHB-C-L2F-S24L-SCCT Series Download File
- Spec Sheet: C-PHB-C-SCCT Series Download File
Specifications
- Applications Gymnasium, Industrial, Manufacturing, Retail, Warehouses
- Factory Installed Emergency Backup No
- Emergency Backup No
- FCC Compliance FCC Part 15, Subpart B, Class A limits for conducted and radiated emissions
- Certifications cULus, Damp Locations, Dimmable, DLC Premium, RoHS
- Color Accuracy ≥ 80 CRI
- Dimensions 23-7/8" L x 13-1/2" W x 3-3/8" H
- Housing Steel construction, white polyester powder-coat finish
- Input Voltage 277 through 480V
- Lens Material Integrated frosted polycarbonate diffuser lens
- Lifespan Estimated > 50,000 hours of maintenance-free operation to L70 at 25°C (77°F)
- Light Output Up to 26,100 Lumens
- Mounting Details V-Hooks (2) included, chains sold separately. Pendant/conduit mount supplied by others.
- Operating Temperature Maximum 104°F (40°C)
- Operating Temperature Minimum -40°F (-40°C)
- Power Consumption 125W/175W
- Replaces 10 x F54T5HO
- Shipping Weight 9.41 (lbs.)
- Typical Mounting Height 15 to 25 feet
- warranty 5-year
Accessories
C-Lite PIR Motion Sensor | 120-277V | White
$59.99
SKU: C-ACC-B-PIR-UL
For use with C-PHB-C, C-STRIP-B, C-WR-B-WLIN4 and C-WR-A-WW4 Series only.
C-Lite 12-Foot Chain Suspension Kit | Steel
$22.99
SKU: C-ACC-A-CHAIN-12FT
Contains 2 chains per kit.
C-Lite LED Linear High Bay Wire Guard | C-PHB-C-L2F-12L, 21L, 24L Series | Silver
$28.99
SKU: C-PHB-C-WG1
For use with C-PHB-C-L2F-12L, 21L, 24L series only.
C-Lite LED Linear High Bay Bi-Level PIR Sensor | 120-480V | White
Your Price $75.99 $80.99
SKU: C-ACC-B-PIR
For use with C-PHB-C and C-HB-B-L2F series only.How much light do you need? Create a custom plan with our simple free tools.
